Fixed LED screen

HD Small Pixel LED video wall

1. Light weight less than 7.8kg for each panel.

2. Low Cost of Splicing: With a perfect panel ratio of 16:9, Radiant HD LED display could be easily spliced in consistent with frequently-used video proportion of 4:3 or 16:9, which could greatly reduce the splicing cost under the dual conditions of prescribed signal source and certain scene.

3. Support for Front Installation and Maintenance: Module, power supply, receiving card, conversion card, and cables between panels could all be maintained from the front. Additionally, the specially-designed panel could be installed from front as well, which makes it more adaptive to the condition with limited space

4. Perfect Display Effect: 160°super wide horizontal and vertical viewing angle covers more potential customers. The broadcasting pictures are stable with no scanning line, and the edge of image is sharp and clear when dealing with dynamic pictures.

5. Safe Operation: With hot double backup for Signal, stable broadcasting would be guaranteed when failure happens.Anti-hacking Encryption could avoid malicious signal cut-off and input.

FEATURES

Item

HD1.667

HD1.875

HD2

Pixel Configuration

SMD LED

SMD LED

SMD LED

Pixel Pitch (mm)

1.667

1.875

2.0

Pixel Density(pixels/㎡)

360000

284000

250000

Panel Size (mm)

400 (W)×300 (H)×88(D)

480 (W)×480 (H)×88(D)

480 (W)×540 (H)×88(D)

Panel Resolution (W×H)

240×180

256×256

240×270

Panel Material

Die - casting aluminum

Die - casting aluminum

Die - casting aluminum

Weight (kg/pcs)

≤6.5

≤7.8

≤10

White balance brightness (nits)

800 adjustable

800 adjustable

800 adjustable

*Max. Power Consumption (W/㎡)

800

800

800

*Avg. Power Consumption (W/㎡)

250

250

250

Serviceability

Front/Rear

Front/Rear

Front/Rear

Viewing Angle (deg.)

160(H)/160(V)

160(H)/160(V)

160(H)/160(V)

Refresh Rate (Hz)

1920/3840

1920/3840

1920/3840

Gray Level (Bit)

14/16/18

14/16/18

14/16/18

Contrast Ratio

3000:1

3000:1

3000:1

Color Temperature (K)

2000 ≤ TC ≤ 9300 adjustable

2000 ≤ TC ≤ 9300 adjustable

2000 ≤ TC ≤ 9300 adjustable

Brightness Adjustment

Programmable/auto/manual

Programmable/auto/manual

Programmable/auto/manual

Color Calibration

Brightness and chroma calibration

Brightness and chroma calibration

Brightness and chroma calibration

Indoor LED screen

Product Detail:

1.Gray level: 65536 level, refresh rate ≥1200Hz, delicate and clear pictures.

2.Higher cost performance, lower maintenance cost.

3.Strictly screening LED wavelength, brightness and voltage, Etc. to ensure the consistency of the whole screen.

4.High quality driving IC, combined with the control system which has more than 14bit processing, effecting a higher gray level.

5.Red, green and blue LED chips incorporated encapsulation, better perspective. Strong adaption to environment

The small chip body combined with black mask, generating a higher contrast ratio.

6.Faster to assemble or disassemble it without any tool.

FEATURES

Item

FXI2.5

FXI3

FXI4

FXI5

FXI6

Pixel Configuration

SMD2121

SMD2121

SMD2121

SMD2121

SMD2121

Pixel Pitch (mm)

2.5

3

4

5

6

Pixel Density(pixels/㎡)

160000

111111

62500

40000

27777

Standard Cabinet Size (mm)

480×480

576×576

512×512

640×640

768×768

Panel Resolution (W×H)

192×192

192×192

128×128

128×128

128×128

Weight (kg/pcs)

≤6.5

≤8

≤6.5

≤10

≤15

White balance brightness (nits)

1200 adjustable

1200 adjustable

1200 adjustable

1200 adjustable

1200 adjustable

*Max. Power Consumption (W/㎡)

800

800

1000

800

800

*Avg. Power Consumption (W/㎡)

250

250

250

250

250

Serviceability

Rear

Rear

Rear

Rear

Rear

Viewing Angle (deg.)

140(H)/140(V)

140(H)/140(V)

140(H)/140(V)

140(H)/140(V)

140(H)/140(V)

Refresh Rate (Hz)

>1200

>1200

>1200

>1200

>1200

Driving Mode

1/32 scan

1/32 scan

1/16 scan

1/16 scan

1/16 scan

Gray Level (Bit)

12/14/16

12/14/16

12/14/16

12/14/16

12/14/16

Contrast Ratio

3000:1

3000:1

3000:1

3000:1

3000:1

Color Temperature (K)

2000 ≤ TC ≤ 9300 adjustable

2000 ≤ TC ≤ 9300 adjustable

2000 ≤ TC ≤ 9300 adjustable

2000 ≤ TC ≤ 9300 adjustable

2000 ≤ TC ≤ 9300 adjustable

Brightness Adjustment

Programmable/auto/manual

Programmable/auto/manual

Programmable/auto/manual

Programmable/auto/manual

Programmable/auto/manual

Color Calibration

Brightness and chroma calibration

Brightness and chroma calibration

Brightness and chroma calibration

Brightness and chroma calibration

Brightness and chroma calibration



Outdoor LED screen

Product Detail:

Outdoor Iron panel which is energy-saving,enviornmental protection,has higher brightness to against glare.

Front panel is IP65 protection,it will be Waterproof,antiseptic,dampproof,anti-thunder,schock proof.

The Simple or seal cabinet can be designed according to your project in reality.

Customized Size will be base on the module size,most suitable solution will be provided.

Features:

 123 Competitive advantage in outdoor SMD design:For DIP LED display, it has only 70° view angle. For SMD LED display, it has bigger view of 120°
 2333 Flexible design for both front and rear service:There are both front and rear service for optional. Modules, power and cards can be take out from front or back.
 3344 If the brightness can be autamatically adjustable, it can save quite a lot of power. Besides, this can successfully avoid light pollution in the evening, which is for drivers and traffic.
 4444 More than 10000 nits high brightess makes it possible to be viewed even the LED displays face the direct sun!
 555 Anti low temperature:suitable for winter and cold areas like North European countries and Russia.

 Specifications



Item

FX04

FXO5

FXO6

FXO8

FXO10

FXO16

Pixel Configuration

SMD1921

SMD2727

SMD3535

SMD3535

SMD3535

DIP346

Pixel Pitch (mm)

4.0

5.0

6.0

8.0

10.0

16.0

Pixel Density(pixels/)

62500

40000

27777

15625

10000

3906

Cabinet Size (mm)

1024X768

800×800

960×960

1024×1024

960×960

1024×1024

Panel Resolution (W×H)

256X192

160×160

160×160

128×128

96×96

64×64

Panel Material

Steel

Weight (kg/pcs)

40

≤28

≤42

≤47

≤42

≤47

White balance brightness (nits)

5500 adjustable

6500 adjustable

6500 adjustable

6500 adjustable

5500 adjustable

7000 adjustable

*Max. Power Consumption (W/)

1000

1000

900

900

800

800

*Avg. Power Consumption (W/)

300

300

300

270

240

240

Serviceability

Rear

Viewing Angle (deg.)

160(H)/140(V)

Refresh Rate (Hz)

>1920

Driving Mode

1/8 scan

1/8 scan

1/8 scan

1/4 scan

1/2 scan

Static constant current

Gray Level (Bit)

12/14/16

Contrast Ratio

3000:1

Color Temperature (K)

3500 ≤ TC ≤ 9300 adjustable

Brightness Adjustment

Programmable/auto/manual

Color Calibration

Brightness and chroma calibration
