Custom LED Displays for Slot Machines | High-Brightness Gaming Signs
High brightness LED display
Customizable logo options
Sleek rectangular design
High-Performance Rectangle LED Displays for Gaming
Elevate gaming environments with Radiant’s high-performance Rectangle LED Displays, engineered specifically for slot machine facilities. Boasting 800-1200 nits ultra-brightness, these displays ensure crystal-clear visibility even in brightly lit casinos, arcades, and entertainment bars.
Technical Excellence
-
1920-3840Hz Refresh RateFlicker-free visual performance
-
160° Wide Viewing AngleOptimal visibility from all directions
-
IP43 ProtectionIndoor environmental resistance
Design Features
IP43
Protection Rating
160mm
Module Size
130W/m²
Power Consumption
100k+
LED Hours
System Advantages
Front magnetic maintenance for tool-free servicing
-10°C to +50°C operational temperature range
Novastar controls with customizable cabinet sizes
2+ years warranty with 24/7 operation support
Details Specification
| Item | RDT-GS002 | Pixel Pitch | 2.0mm,2.5mm |
| Module size | 160mm x 160mm | Cabinet size | Customized based on module size |
| Cabinet Weight | 35 kg/m² | Physical Density | 250000 dots/m², 160000 dots/m² |
| Brightness | 800-1200nits | Refresh Rate | 1920-3840 Hz |
| Driving Mode | Constant Current 1/32 | Gray Level | 16 bit |
| Working Voltage | 100-240V AC, 50&60Hz | Protection Level | IP43 |
| Maximum Power Consumption | 460W /m² | Average Power Consumption | 130W /m² |
| View Angle | 160ºH/140ºV | Viewing Distance | >2m,2.5m |
| Working Temperature | -10℃~ +50 ℃ | Working Humidity | 10 – 95 % RH |
| LED Life(Normal Tep) | 100,000 Hours | Software System | Novastar |
| Application | Indoor | Installation Type | Fixed installation |
| Maintenance Method | Front (Magnetic module) | Warranty | >2 years |
